- “B” Hot Stick Hook – have 1” welded steel rings on the hook
- This option also adds hot stick rings to the pawl shafts and handle
- Hoists meet the ASME B30.21 spec
- Goes further with our stress link overload warning system
- RFID Tracking
- Oiled for life bearings
- Synthetic web strap
- Interlocking pawl system
- USA forged steel hooks
- Reversible handle with 2 spare stress links
- 1-1/4” OD fiberglass handle for extra stiffness
- Double flanged drum – keeps web strap from coming in contact with ratchet teeth
- The standard series feature models from 2000 to 4000 lb capacity.
Product Specifications
- Handle Length: 30”
- Single Line Capacity: 1000 lbs; ½ Tons
- Single Line Lifting Dist: 9 ft
- Single Line Minimum Hook to Hook: 18”
- Double Line Capacity: 2000 lbs; 1 Ton
- Double Line Lifting Dist.: 4-1/2 ft.
- Double Line Minimum Hook to Hook: 23”
- Hoist Weight: 10-1/4 lbs.
Description
- “B” Hot Stick Hook – have 1” welded steel rings on the hook
- This option also adds hot stick rings to the pawl shafts and handle
- Hoists meet the ASME B30.21 spec
- Goes further with our stress link overload warning system
- RFID Tracking
- Oiled for life bearings
- Synthetic web strap
- Interlocking pawl system
- USA forged steel hooks
- Reversible handle with 2 spare stress links
- 1-1/4” OD fiberglass handle for extra stiffness
- Double flanged drum – keeps web strap from coming in contact with ratchet teeth
- The standard series feature models from 2000 to 4000 lb capacity.
Product Specifications
- Handle Length: 30”
- Single Line Capacity: 1000 lbs; ½ Tons
- Single Line Lifting Dist: 9 ft
- Single Line Minimum Hook to Hook: 18”
- Double Line Capacity: 2000 lbs; 1 Ton
- Double Line Lifting Dist.: 4-1/2 ft.
- Double Line Minimum Hook to Hook: 23”
- Hoist Weight: 10-1/4 lbs.
