MAGNA 1/2 Ton Lever Hoist, 10 ft. Lift LH05010
The MAGNA LH05010 1/2 Ton Lever Hoist takes the robust, repairable design of the LH050 series and equips it with 10 feet of Grade 80 load chain. This extended reach makes it the perfect solution for facility maintenance tasks where lifting points are often located high above the working floor. Whether lifting pipes into ceiling racks or hoisting motors onto elevated platforms, the LH05010 provides the reach needed without requiring additional rigging extensions. The unit remains compact and manageable, weighing approximately 10 lbs.
Like all MAGNA industrial hoists, it features a fully enclosed steel gear case and a Weston-style mechanical brake that provides positive load control. The 10-foot chain is alloy steel for maximum strength and wear resistance. The hoist is designed for ease of maintenance, with a completely repairable chassis and readily available spare parts. Tested to 1,650 lbs (150% capacity) and rated for -45°C, it is a dependable tool for year-round industrial use.
Features & Benefits
- 10-Foot Lift: Ideal for elevated installation and maintenance work.
- Fully Repairable: Sustainable design allows for indefinite service life through part replacement.
- 150% Proof Load: Tested to ensure maximum safety margins.
- Cold Weather Grease: Prevents brake lock-up in freezing conditions (-45°C).
- Robust Steel Body: Protects gears from impact and debris on active jobsites.
- Smooth Operation: Precision gearing reduces operator effort to 93 lbs.
Compatible Accessories: Zinc Plated Load Chain, Chain Bag, PTR050 (1/2 Ton Plain Trolley - Hook Mount), BC100P/BC100RE (1 Ton Beam Clamp)
Specifications
- Model Number: LH05010
- Working Load Limit (WLL): 1/2 Ton (1,100 lbs)
- Standard Lift: 10 ft.
- Load Chain Dimensions: 5.0 x 15.0 mm
- Load Chain Grade: Grade 80 Alloy
- Number of Falls: 1
- Pull to Lift Full Load: 93 lbs
- Headroom (Dimension C): 11.4 in.
- Handle Length (Dimension D): 8.9 in.
- Hook Throat Opening (Dimension G): 0.86 in.
- Net Weight: 10.0 lbs
