HTP Rig
HTP Rig
The HTP RIG Static ropes are rigging and hauling ropes with ultra-low stretch for efficiency.
Details
HTP Rig are your go-to ropes for tough jobs. Built to withstand harsh conditions, these ropes are resistant to abrasion, water, chemicals, and UV. With ultra-low elongation and tight sheaths, these ropes resist picking and are compatible with a wide range of rigging equipment.
- 100% Polyester
- Hydrophobic
- Durable in all conditions
- Colors: Black and white with pink tracer (tracer pattern indicates diameter)
- 3 Diameters: 7/16" (11.0 mm), 1/2" (12.5 mm, 5/8" (16.0 mm)
- Available Lengths: 50, 100, 200 m
Technical Specs 7/16" HTP 1/2" HTP 5/8" HTP
Diameter (mm) 11.0 12.5 16.0
Weight (lb/100') 6.5 8.0 12.5
Weight (g/m) 97 119 186
MBS Rating (lb/kg) 6,856 / 3,116 9,081 / 4,128 12,993 / 5,906
MBS Rating (kN) 30.5 40.4 57.8
Elongation (at 10% MBS) 4.0 2.0 2.8
Sheath/Core Percentage 42.8% / 57.2% 37.9% / 62.1% 39.7% / 60.3%
Sheath/Core Material Polyester/Polyester Polyester/Polyester Polyester/Polyester
WLL (5:1) (lbs/kg/kN) 1,371 / 623 / 6.1 1,816 / 826 / 8.1 2,599 / 1181 / 11.6
Lengths Available 50, 100, 200m
