MAGNA Lifting Products 3 Ton Chain Hoist, 15 ft. Lift (Single Fall) CH30015SF

The MAGNA CH30015SF offers the power of a 3 Ton (6,600 lbs) hoist with the efficiency of a single-fall chain design and an extended 15-foot lift. By using high-strength Grade 100 alloy chain, this model eliminates the bottom sheave block, making it lighter and easier to deploy in high-reach applications compared to traditional double-fall hoists. It is particularly effective for construction sites and mobile rigging where speed and reach are critical.

Designed for professional use, the CH30015SF features a rugged steel body and premium cold-weather lubrication (-49°F). The single-fall design minimizes chain twisting, a significant benefit when working with longer 15-foot lifts. Fully repairable and proof tested to 150% capacity, this hoist delivers both performance and peace of mind.

Features & Benefits

• Efficient Reach: 15-foot lift with single-fall speed and simplicity.
• Grade 100 Chain: High-strength alloy reduces weight and bulk.
• Tangle Free: Single line design prevents chain twisting at height.
• Durable Build: Impact-resistant steel housing for field use.
• Cold Ready: Reliable operation down to -45°C (-49°F).
• Safety Certified: Meets ANSI B30.16 standards with 150% proof test.

Compatible Accessories: Chain Bag, Lug Mount Attachment, Self-Locking Hook, Shipyard Hook, Zinc Plated Load Chain, Slip Clutch, PTR300 (3 Ton Plain Trolley), GTR300 (3 Ton Geared Trolley), BC300P/BC300RE (3 Ton Beam Clamps), ULBC300F/FW/S (3 Ton Universal Beam Clamps)

Specifications

• Model Number: CH30015SF
• Working Load Limit (WLL): 3 Ton (6,600 lbs)
• Standard Lift: 15 ft.
• Load Chain Dimensions: 9.0 x 27.0 mm
• Load Chain Grade: Grade 100
• Number of Falls: 1
• Pull to Lift Full Load: 79 lbs
• Headroom (Dimension C): 25.00 in.
• Hook Throat Opening (Dimension G): 1.69 in.
• Net Weight: 67.0 lbs
