FEATURES:
- Kevlar® web lifeline protects against Arc Flash hazards
- Features comprehensive fall clearance charts and tables inside the Kevlar®/Nomex® energy absorber cover
- Compact design elevates the SRDs to align optimally with worker motion, increasing both comfort and productivity
- Features alloy steel carabiner with 5,000 lbs. rated gate for tie-back connections
- Suitable for below D-ring tie-off up to five feet when no edge hazards exist; outside the scope of ANSI Z359
- Rated for workers weighing up to 420 pounds, including clothes, tools, gear, etc.
- Complies with ANSI Z359.14-20121 Class 1 SRL-P and ASTM F887-20. Learn more and download White Paper
- Meets ASTM F887 Standards
MATERIAL SPECIFICATIONS:
- Webbing: Kevlar®; 4,500 lb min.
- Energy Absorber: Polyester tear-away
- Anchorage Connector: Plated alloy steel; 5,000 lb min. static strength with 5,000 lb gate strength
- Dorsal Connector: Aluminum alloy; 3,600 lb min.
PERFORMANCE SPECIFICATIONS:
- Static Strength 3,600: lb min.
- ANSI SRL Class/Type: Class 1 SRL-P
- Avg. Arrest Force: 1,350 lb max.
- Max. Arrest Force: 1,800 lb
- Max. Arrest Distance: 42"
- ANSI User Capacity: 130 to 310 lb max.
- OSHA User Capacity: 130 to 420 lb max.
